Factory 3.2mm silicon TO5 package planar PIN PD photodiode module

This silicon photodiode delivering high-speed response for optical communications and optical disk pickup.

File Name : Format: Size:

Description Feedback

Features

High reliability, Ultra low dark current;

Top illumination Planar PIN PD;

Active area 3.2x3.2mm;

Hermetic TO5-CAN package.

Applications

Optical sensor;

High speed light pulse test;

Industrial automatic control;

Science analysis and experiment;

Space light detect equipment.

Electro-Optical Parameters

Parameters	Symbol	Test conditions	Value	Unit
Detection range	λ_d	-	400 ~ 1100	nm
Detect area	Φ	-	3.2x3.2	mm
Responsivity	Re	λ=650nm	0.35	mA/mW
		λ=850nm	0.5
		λ=1064nm	0.2
Dark current	I_D	V_R=0V	5	pA
Dark current	I_D	V_R=5V	400	pA
Response time	T_R	R_L =50Ω,V_R =5V	6	ns
Reverse break voltage	V_BR	I_R=10uA	100	V
Junction capacitance	Cj	f=1MHz, V_R=0V	250	pF
Junction capacitance	Cj	f=1MHz, V_R=5V	25	pF
Saturated optical power	P_S	V_R=5V	25	mW
Operating voltage	V_R	-	0-15	V
Shunt resistance	R_Sh	V_R =10mV	2	GΩ
Package	Hermetic TO5-CAN package
