Apodized Fiber Grating
Fiber Bragg Gratings is one of the most meaningful developments in the areas of optical fiber technology, due to their flexibility and unique filtering performance. FBG are defined as the key components in dense wavelength division multiplexing on the basis of their low insertion loss, high wavelength selectivity, low polarization dependent loss, and low polarization modal dispersion.

File Name : Format: Size:

Description Feedback
Features
Wide bandwidth;
Easy to daisy-chain;
Low cost and long lifetime.

Applications
Telecom;
Sensing;
Instrumentation;
Microwave photonics;
Industrial.

Electro-Optical Parameters

Parameter

Unit

Type

Tolerance

Center Wavelength

nm

1550

±0.05

Reflectivity



(1-99.999)%

±0.5%

FWHM

nm

2-30

SMSR

dB

>20

FBG Length

mm

0.2-50

Recoating

Acrylate

Fiber Type

HI 980, HI1060, SMF-28e, PM980, PM1550 or Custom

Operating Temperature

-5~80℃

Dispersion

33.3ps/nm; 555.6ps/nm


Package

Original Carton Package;
As customers‘ requirement.

Shipping
5-10 Working days after receive the payment;
Shipment: Air transportation(DHL / UPS / TNT / Fedex / EMS / CHINA POST);
Shipping fee depends on the weight and size.


Payment
For large orders: T/T, Credit card;
For small orders: Paypal are accepted.

Warranty
All products have been tested before shipping out;
All products have 1-3 years warranty.(After the quality guarantee period began to charge appropriate maintenance service fee.)

Refund & Replacement
We appreciate your business and offer an instant 7 days return policy. (7 days after receiving the items);
If the items you purchase from our store are not of perfected quality, that is they don‘t work electronically to manufacturers specifications, simply return them to us for replacement or refund;
If the items are defective, please notify us within 3 days of delivery;
Any items must be returned in their original condition to qualify for a refund or replacement;
The buyer is responsible for all the shipping cost incurred.
